Waterborne Industrial Coatings-Low VOC, High Performance
A complete system of TDI and HDI aliphatic polyurethane topcoats, high-solids anticorrosive finishes, micaceous iron oxide intermediate coats and polyurethane rust-inhibiting primers — engineered for steel structures, bridges, petrochemical plants and offshore facilities requiring ISO 12944 C4–C5 performance.
Products
product Groups
Water-Based / Non-Flammable
Rust converter, epoxy zinc-rich, alkyd
MIO, antistatic, thermal insulation
Epoxy, acrylic, polyurethane, alkyd
Fluorocarbon, antimould
Amino baking, dip coat, insulating varnish
Waterborne Coating Products
23 water-based industrial coating products organised into five functional groups — from corrosion-inhibiting primers and barrier intermediate coats to decorative topcoats, ultra-durable fluorocarbon finishes and high-temperature baking enamels.
The Huili Coating Waterborne Coatings Series is a complete portfolio of water-based industrial protective and decorative coatings covering every layer of a corrosion protection system — from water-based epoxy zinc-rich primer and rust converter through micaceous iron oxide intermediate coats to acrylic, polyurethane and fluorocarbon topcoats. All 23 products use water as the sole diluent, delivering low VOC, non-flammable handling and compliance with increasingly stringent environmental regulations in industrial coating operations. The series serves a broad range of end markets including structural steel corrosion protection, petrochemical storage tank lining, building facade coating, industrial equipment finishing and electrically sensitive components requiring antistatic or insulating properties. Products are formulated for application by spray, brush or roller at substrate temperatures from 5 °C, with pot lives of 3–5 hours for two-component grades and unlimited working time for single-component waterborne systems.
Anti-Rust Primers (5)
PLSX-22 Waterborne Inorganic Zinc-Rich Anti-Corrosion Primer
Single-component water-based inorganic zinc-rich primer with cathodic protection, self-repairing capability and 400°C heat resistance for oil tanks, bridges and transmission towers. Low-VOC, non-flammable. Sa2.5 prep, 50µm DFT per coat.
PLSX-05 Waterborne Alkyd Anti-Rust Coating
Single-component water-based alkyd anti-corrosive primer with fast-drying, tough film and strong adhesion for steel structures, industrial equipment and metal fabrications. Low-VOC, non-flammable formulation. Sa2.5 prep, 50µm DFT per coat.
PLSX-04 Waterborne Epoxy Zinc-Rich Anti-Corrosion Primer
2K water-based epoxy zinc-rich primer with cathodic protection and high mechanical film strength for ships, offshore platforms and petrochemical storage tanks. Low-VOC, non-flammable formulation. Sa2.5 prep, 50µm DFT per coat.
PLSX-02 Waterborne Rust Conversion Primer
Single-component water-based rust converter primer that chemically converts rust into a stable film component for tanks, bridges, pipelines and automotive components. Low-VOC, fast surface dry in 30 minutes. 40µm DFT per coat.
PLSX-01 Waterborne Rust-Tolerant Anti-Rust Primer
Single-component water-based rust-tolerant primer with low VOC for lightly corroded steel structures where thorough rust removal is impractical. Reduces surface preparation time and cost. Surface dry in 1 hour, 50µm DFT per coat.
Intermediate & Specialty Coats (4)
PLSX-19 Waterborne Epoxy Ester Coating
Single-component water-based epoxy ester coating with strong adhesion and corrosion resistance for steel structures, bridges and chemical equipment. Non-flammable, low-VOC formulation suited for indoor metal decorative and protective applications. Sa2.5 prep, 50µm DFT per coat.
PLSX-18 Waterborne Thermal Insulation Coating
Water-based thermal reflective insulating coating with hollow microsphere reinforcement for metal tanks, refrigerated facilities and concrete buildings. Reduces surface temperature with measurable interior-exterior temperature differential. Sa2.5 prep, 200µm+ total DFT system.
PLSX-14 Waterborne Epoxy Antistatic Coating
2K water-based epoxy anti-static coating with excellent oil, water and corrosion resistance for crude oil, gasoline and diesel storage tank interiors. Low-VOC, non-flammable formulation. Sa2.5 prep, 40µm DFT per coat.
PLSX-06 Waterborne Epoxy MIO Intermediate Coating
2K water-based epoxy MIO intermediate coat with outstanding anti-permeation barrier performance and abrasion resistance for bridges, chemical plants and municipal steel structures. Increases total system thickness. Sa2.5 prep, 50µm DFT per coat.
Industrial Topcoats (5)
PLSX-21 Waterborne Alkyd Enamel Coating
Single-component water-based alkyd enamel with high-gloss film, strong adhesion and corrosion resistance for scaffolding, structural steel, outdoor steel fabrications and machinery. Low-VOC, non-flammable. Sa2.5 prep, 50µm DFT per coat.
PLSX-20 Waterborne Polyurethane Topcoat
2K water-based polyurethane topcoat with long-term color and gloss retention for light to medium corrosive environments. Pairs with water-based epoxy primers for a complete system. Sa2.5 prep, 40µm DFT per coat.
PLSX-16 Waterborne Alkyd General-Purpose Coating
Single-component water-based alkyd enamel with tough film, strong adhesion and corrosion resistance for indoor and outdoor metal and wood structures. Non-flammable, low-VOC formulation. Sa2.5 prep, 50µm DFT per coat.
PLSX-08 Waterborne Acrylic Anti-Corrosion Topcoat
Single-component water-based acrylic topcoat with fast-drying, tough film and strong adhesion for automotive chassis, steel structures, guardrails and pipelines. Low-VOC, suited for indoor and outdoor applications. Sa2.5 prep, 50µm DFT per coat.
PLSX-07 Waterborne Epoxy Anti-Corrosion Topcoat
2K water-based epoxy topcoat with chemical, acid, alkali and moderate solvent resistance for steel structures, ships and machine tools. Low-VOC, easy application on steel, wood and concrete. Sa2.5 prep, 50µm DFT per coat.
High-Performance Finishes (3)
PLSX-17 Waterborne Fluorocarbon Protective Coating
2K water-based fluorocarbon topcoat with outstanding UV resistance and long-term color and gloss retention for bridges, transmission towers and chemical equipment. Low-VOC, non-flammable crosslinked formulation. Sa2.5 prep, 50µm DFT per coat.
PLSX-13 Waterborne Anti-Mold Coating
Single-component water-based anti-mold coating with broad-spectrum mold inhibition and durable anti-corrosive performance for food processing, brewing and pharmaceutical facility interiors. Low-VOC, non-flammable formulation. Surface dry in 1 hour, 50µm DFT per coat.
PLSX-12 Waterborne Fluorocarbon Coating
Single-component water-based fluorocarbon coating with outstanding UV resistance and long-term color and gloss retention for building exteriors and roofing. Low-VOC, non-flammable formulation. Surface dry in 1.5 hours, 50µm DFT per coat.
Baking & Specialty Finishes (5)
PLSX-23 Waterborne Insulating Dip Coating
Single-component water-based insulating dip coating with excellent dielectric performance and water resistance for transformers, motors, generators and circuit boards. Uniform film formation with minimal application loss. Bake cure at 120–150°C, 25µm DFT.
PLSX-15 Waterborne Dip-Coating Coating
Single-component water-based dip coating delivering uniform film formation with minimal application loss for vehicle frames, chassis, agricultural equipment and petrochemical hardware. Low-VOC, non-flammable. Customizable resin system per production line requirement, 25µm DFT.
PLSX-11 Waterborne Amino Baking Coating
Single-component water-based amino baking enamel with impact resistance, high hardness and flexible film for bicycles, home appliances and precision instrument metal components. Low-VOC, non-flammable. Bake cure at 120–130°C for 30 minutes, 25µm DFT.
PLSX-10 Waterborne Acrylic Amino Silver Metallic Baking Coating
Single-component water-based acrylic amino metallic baking enamel with aluminum flake sparkle, high hardness and scratch resistance for bicycles, home appliances and instrument components. Outstanding color and gloss retention. Bake cure at 130°C, 30µm DFT.
PLSX-09 Waterborne Acrylic Amino Baking Coating
Single-component water-based acrylic amino baking enamel with high hardness, scratch and impact resistance for bicycles, home appliances and precision instrument metal components. Outstanding color and gloss retention. Bake cure at 130°C for 30 minutes, 25µm DFT.
Full Specification Comparison
Key parameters across all 22 waterborne coating products. Scroll horizontally to view all columns; scroll vertically to browse all products. Group dividers mirror the product accordion above.
| Product | DFT / Coats | App. Rate | Pack Type | Pot Life | Surface Dry | Min Temp | Application | Key Feature |
|---|---|---|---|---|---|---|---|---|
| GROUP 1 — ANTI-RUST PRIMERS | ||||||||
| PLSX-01 Waterborne Rust-Tolerant Primer | 50 μm / coat | 130 g/m² | 1-Pack | — | 1 h | 5 °C | Spray / Brush / Roll | Rust-tolerant, no blast required |
| PLSX-02 Waterborne Rust Converter Primer | 40 μm / 1–2c | 100 g/m² | 1-Pack | — | 30 min | 5 °C | Spray / Brush / Roll | Active rust conversion |
| PLSX-03 Waterborne Epoxy Iron-Red Primer | 50 μm / coat | 140 g/m² | 2-Pack | 3 h | 1 h | 5 °C | Spray / Brush / Roll | Salt spray resistant |
| PLSX-04 Waterborne Epoxy Zinc-Rich Primer | 50 μm / coat | ~250 g/m² | 2-Pack | 3 h | 1 h | 5 °C | Spray / Brush / Roll | Cathodic protection |
| PLSX-05 Waterborne Alkyd Anti-Rust Primer | 50 μm / coat | 200 g/m² | 1-Pack | — | 1 h | 5 °C | Spray / Brush / Roll | General industrial, fast dry |
| PLSX-22 Waterborne Inorganic Zinc-Rich | 50 μm / coat | ~260 g/m² | 1L+1P | 5 h | 0.5 h | 5 °C | Spray / Brush / Roll | 400 °C resistant, self-repair |
| GROUP 2 — INTERMEDIATE & SPECIALTY COATS | ||||||||
| PLSX-06 Waterborne Epoxy MIO Intermediate | 50 μm / coat | 150 g/m² | 2-Pack | 3 h | 1 h | 5 °C | Spray / Brush / Roll | MIO barrier shielding |
| PLSX-14 Waterborne Epoxy Antistatic | 40 μm / coat | 110 g/m² | 2-Pack | 3 h | 2 h | 10 °C | Spray / Brush / Roll | Conductive mica, tank lining |
| PLSX-18 Waterborne Thermal Insulation System | 200 μm total | System | Multi | — | 2 h | 5 °C | Spray / Brush / Roll | Hollow microsphere insulation |
| PLSX-19 Waterborne Epoxy Ester Coating | 50 μm / coat | 160 g/m² | 1-Pack | — | 3 h | 5 °C | Spray / Brush / Roll | Epoxy ester, indoor safe |
| GROUP 3 — INDUSTRIAL TOPCOATS | ||||||||
| PLSX-07 Waterborne Epoxy Topcoat | 50 μm / coat | 120 g/m² | 2-Pack | 3 h | 2 h | 5 °C | Spray / Brush / Roll | Chemical & solvent resistant |
| PLSX-08 Waterborne Acrylic Topcoat | 50 μm / coat | 140 g/m² | 1-Pack | — | 1 h | 5 °C | Spray / Brush / Roll | Fast dry, vehicle / rail |
| PLSX-20 Waterborne PU Topcoat (2-Pack) | 40 μm / coat | ~110 g/m² | 2-Pack | 3 h | 2 h | 5 °C | Spray / Brush / Roll | Long-term gloss retention |
| PLSX-21 Waterborne Alkyd Enamel | 50 μm / coat | ~140 g/m² | 1-Pack | — | 3 h | 5 °C | Spray / Brush / Roll | Gloss finish, scaffold / outdoor |
| PLSX-16 Waterborne Alkyd Blending Enamel | 50 μm / coat | 150 g/m² | 1-Pack | — | 24 h | 5 °C | Spray / Brush / Roll | General purpose, metal & timber |
| GROUP 4 — HIGH-PERFORMANCE FINISHES | ||||||||
| PLSX-12 Waterborne Fluorocarbon (1-Pack) | 50 μm / coat | 150 g/m² | 1-Pack | — | 1.5 h | 5 °C | Spray / Brush / Roll | Building facade, UV stable |
| PLSX-17 Waterborne Fluorocarbon (2-Pack) | 50 μm / coat | 160 g/m² | 2-Pack | 3 h | 2 h | 5 °C | Spray / Brush / Roll | Crosslinked, tower / bridge |
| PLSX-13 Waterborne Antimould Coating | 50 μm / coat | 130 g/m² | 1-Pack | — | 1 h | 5 °C | Spray / Brush / Roll | Broad-spectrum antimould |
| GROUP 5 — BAKING & SPECIALTY FINISHES | ||||||||
| PLSX-09 Waterborne Acrylic Amino Baking | ~25 μm / coat | 105 g/m² | 1-Pack | — | Bake 130 °C / 30 min | 5 °C | Spray / Brush | Hardness + colour retention |
| PLSX-10 Waterborne Silver Metallic Baking | 30 μm / coat | 100 g/m² | 1-Pack | — | Bake 130 °C / 30 min | 5 °C | Spray / Brush | Aluminium flake metallic |
| PLSX-11 Waterborne Amino Baking Enamel | ~25 μm / coat | 100 g/m² | 1-Pack | — | Bake 120–130 °C / 30 min | 5 °C | Spray / Brush | Impact resistant, cost-effective |
| PLSX-15 Waterborne Dip Coat | 25 μm / coat | 80–110 g/m² | 1-Pack | — | Per line spec | 5 °C | Dip | Production line, uniform film |
| PLSX-23 Waterborne Insulating Varnish | 25 μm / coat | 80–100 g/m² | 1-Pack | — | Bake 120–150 °C / 40–60 min | 5 °C | Dip | Dielectric insulation, motor / transformer |
Application Environments
The waterborne coatings series spans four distinct end-use sectors, each requiring specific product combinations from the five groups above.
Bridges & Structural Steel
Bridges, transmission towers, TV masts and industrial steel frameworks demand coating systems with superior adhesion, mechanical toughness and colour retention over 10+ year service cycles. The PLS53-61 primer → PLS53-62 MIO intermediate → PLS52-3 HDI aliphatic topcoat system meets ISO 12944 C4–C5 requirements for structural steel corrosion protection.
Vehicles & Engineering Machinery
Construction machinery, agricultural equipment and industrial vehicles require coating systems that resist mechanical abrasion, oil contamination and repeated washing cycles. The PLS52-1 and PLS52-3 polyurethane topcoat systems combine toughness, boiling-water resistance and decorative gloss to protect working machinery in harsh environments.
Storage Tanks & Chemical Vessels
Tank internal linings must resist the stored medium — crude oil, refined products or aggressive chemicals. Solvent-free and heavy-duty systems are engineered for full-immersion service.
Commercial & High-Rise Buildings
Structural steel in multi-storey office buildings, shopping centres and high-rise residential towers requires passive fire protection compliant with local building codes. GT-NSP-Fp2.00 indoor intumescent coating delivers a 2-hour fire resistance rating at 3.3 mm DFT, with a decorative topcoat option for exposed steel in architectural environments. Application by spray or roller allows efficient coverage on complex beam and column sections.
Technical Articles & Guides
Switching from solvent-borne to waterborne industrial coatings requires a clear understanding of resin chemistry, surface preparation differences, pot life management and system compatibility. The resources below provide practical guidance for specifiers, applicators and procurement teams evaluating waterborne coating systems for industrial and architectural projects.
Request a Technical Recommendation
Tell us your substrate, environment and project scale — our technical team will recommend the right system and provide a quotation within 24 hours.
- Response within 24 hours
- Free technical consultation
- TDS & safety data sheets provided
