PLS52-4 High-solids polyurethane anti-corrosion topcoat

High-solids polyurethane anti-corrosion topcoat (2K) for high-build steel structure protection.

For petrochemical, power, bridges, port facilities.
Mixing ratio 7:1; pot life 3 h.
Low VOC 305 g/L; artificial weathering 1500 h.

HUILI anti-rust coatings metal paint pail

PLS52-4 High-solids polyurethane anti-corrosion topcoat Description

Overview
Two-component high-solids polyurethane anti-corrosion topcoat with low VOC (305 g/L).
Suitable for high-build application; artificial weathering resistance: 1500 h.

Composition
Based on acrylic polyol resin, polyurethane reactive diluent, and chain extender as main film-formers, with pigments and additives.
Cured with polyisocyanate adduct; supplied in Part A & Part B packs.

Typical uses
Long-term protection and finishing for equipment/facility steel structures in various environments, such as petrochemical, power, wind power, cast pipe, bridges, and port facilities.

Technical data (typical)

Appearance: Various colors.
Theoretical consumption: 0.108 L/m²; 0.14 kg/m² at 70 μm DFT (excluding loss).
Density: 1.3 kg/L.
Solids: 80% (by weight); 65% (by volume).
Drying time (25°C): Surface dry 2 h; hard dry 24 h; fully cured 7 d.

Application data (25°C)

Mixing ratio (Part A:Part B): 7:1.
Induction time: 5 min.
Pot life: 3 h.
Application methods: Airless spray, brush, roller.
Thinner: X-7 polyurethane thinner; dilution 3–7%.
Recoat interval (25°C): Min 24 h; max 7 d.
Recommended coats / DFT: 1 coat 30–70 μm; brush/roller 1 coat 30–45 μm.

Surface preparation
Remove dust and oil contamination from the previous coat; if beyond maximum recoat interval, roughen the surface.
When used as the first coat: blast/shot blast to Sa 2.5 or power-tool cleaning to St 3; surface profile 30–75 μm.

System compatibility / packing / storage

Compatibility: Previous coat—polyurethane intermediate coating; epoxy primer; epoxy intermediate coating.
Packing: Part A 21 kg; Part B 3 kg.
Storage: Shelf life 12 months; store dry/cool/ventilated, away from fire and direct sunlight; no outdoor stacking.

Contact Us

We would love to speak with you.
Feel free to reach out using the below details.

PLX06 Vinyl Phosphating Primer

Vinyl Phosphating Primer (2K) – Two-component phosphating primer for galvanized steel, aluminum, and other light metals.

Forms chemical adhesion to improve intercoat adhesion of subsequent coatings.
Low film thickness system: 15–25 µm DFT per coat; theoretical consumption 0.06 kg/m² at 20 µm DFT.
Min. recoat 2 h (25°C); dedicated PLX06 thinner (10–20%).

PLH-20 Special Epoxy Primer

Special Epoxy Primer (2K) – Two-component special epoxy primer for industrial corrosion protection.

For power, bridge, petrochemical, marine, and port facilities/equipment.
Pot life 2 h (25°C); mix ratio 25:2.5.
Compatible with epoxy MIO intermediate and epoxy/PU topcoat systems.

PLH53-8 Modified Epoxy Iron Oxide Red Anti-Rust Primer

Modified Epoxy Iron Oxide Red Primer (2K) – Two-component modified epoxy iron oxide red anti-rust primer for steel and concrete.

For corrosion protection of steel structures and concrete surfaces.
Water and corrosion resistance with strong adhesion (as described).
Mix ratio 24:3; recoat 24 h–7 d (25°C).

PLH53-6 Epoxy Zinc Phosphate Anti-Rust Primer

Epoxy zinc phosphate anti-rust primer (2K) for heavy-duty steel corrosion protection.

For ports/docks, heavy structures, mining machinery, power machinery plants, and water conservancy steelwork.
Zinc phosphate anti-rust pigment system with stated water and salt water resistance.
Mix ratio 7:1; theoretical consumption 0.12 kg/m² at 50 µm DFT.
