Polyurethane Anti-Corrosion Coatings
A complete system of TDI and HDI aliphatic polyurethane topcoats, high-solids anticorrosive finishes, micaceous iron oxide intermediate coats and polyurethane rust-inhibiting primers — engineered for steel structures, bridges, petrochemical plants and offshore facilities requiring ISO 12944 C4–C5 performance.
Products
Max DFT Single Coat
Weathering Resistance
Polyurethane Coating Products
Six 2-pack polyurethane formulations covering the full protective system — from iron-red primer and micaceous iron oxide intermediate to TDI gloss topcoat, HDI aliphatic premium finish and high-solids direct-to-metal anticorrosive. Each product achieves dry film thickness of 30–100 μm per coat and cures at temperatures from 5 °C.
Polyurethane Coating (5)
PLS52-4 High-solids polyurethane anti-corrosion topcoat
2K high-solids polyurethane topcoat with low VOC (308g/L) and 1,500-hour UV resistance for steel and concrete structures. Engineered for petrochemical, power generation, wind energy and bridge applications. Single coat achieves 80–100µm DFT.
PLS52-3 Aliphatic polyurethane premium topcoat
2K aliphatic polyurethane topcoat with outstanding UV stability, color retention and weathering resistance for long-term structural protection. Engineered for bridges, transmission towers, offshore and port facilities. Surface dry in 1 hour, 30–40µm DFT.
PLS52-1 Polyurethane enamel
2K polyurethane enamel with abrasion-resistant, high-gloss film and broad chemical resistance for steel and concrete structures. Suited for metallurgy, petrochemical plants, bridges and port facilities. Surface dry in 2 hours, 70–100µm DFT system.
PLS53-62 Polyurethane micaceous iron oxide anti-rust coating / intermediate coating
2K polyurethane MIO primer and intermediate coat with outstanding barrier performance and inter-coat adhesion for steel structures. Suited for chemical plants and aggressive corrosive environments. Fast-drying, 45µm DFT per coat.
PLS53-61 Polyurethane red iron oxide anti-rust primer
2K polyurethane iron oxide primer with excellent adhesion and corrosion protection for steel, concrete and aluminum alloy surfaces. Fast-drying with low-temperature cure capability. Sa2.5 prep required, 35µm DFT per coat.
About Polyurethane Anti-Corrosion Coatings
The Huili Coating Polyurethane Coatings Series covers the complete 2-pack polyurethane protective and decorative system — from surface-tolerant anti-rust primers and micaceous iron oxide intermediate coats to TDI gloss enamels, HDI aliphatic non-yellowing topcoats and high-solids direct-to-metal finishes. Each product is formulated to ISO 12944 C3–C5 corrosion category requirements, offering dry film builds of 30–100 μm per coat, low-temperature application from 5 °C and service lives exceeding 10 years on properly prepared steel and concrete substrates. The series is widely specified for structural steel corrosion protection, petrochemical plant maintenance coating, offshore wind turbine tower coating, bridge repainting and heavy engineering machinery finishing across global export markets.
Full Parameter Comparison
Key specifications across all 5 polyurethane products to support system selection, project specification writing and procurement.
| Product | DFT / Coats | Mix Ratio (A:B) | Pot Life | Surface Dry | Min Temp | Application | Key Feature |
|---|---|---|---|---|---|---|---|
| PLS52-1 Polyurethane Enamel Topcoat | 70–100 μm / 2–3c | 4:1 | 4 h | 2 h | 5 °C | Spray / Brush / Roll | TDI, boiling water resistant |
| PLS52-2 2-Pack PU Topcoat | 70–100 μm / 2–3c | — | 4 h | 2 h | 5 °C | Spray / Brush | Standard gloss & colour |
| PLS52-3 HDI Aliphatic PU Premium Topcoat | 30–40 μm / coat, 2–3c | 6:1 | 4 h | 1 h | 5 °C | Spray / Brush | HDI aliphatic, UV stable |
| PLS53-61 PU Iron-Red Anti-Rust Primer | 60–70 μm / 2c | 4:1 | 4 h | 2 h | 5 °C | Spray / Brush / Roll | High adhesion, fast dry |
| PLS53-62 PU MIO Intermediate Coat | ~45 μm / 1c (2c severe) | 4:1 | 4 h | 2 h | 5 °C | Spray / Brush / Roll | MIO + zinc phosphate barrier |
| PLS52-4 High-Solids PU Anticorrosive Topcoat | 80–100 μm / 1c | — | — | 2 h | 5 °C | Spray / Brush / Roll | VOC ≤308 g/L, 1500h weathering |
Application Environments
The polyurethane coating system is specified across corrosion categories C3–C5 for structural steel, infrastructure and heavy industry assets requiring both long-term corrosion protection and high decorative quality.
Bridges & Structural Steel
Bridges, transmission towers, TV masts and industrial steel frameworks demand coating systems with superior adhesion, mechanical toughness and colour retention over 10+ year service cycles. The PLS53-61 primer → PLS53-62 MIO intermediate → PLS52-3 HDI aliphatic topcoat system meets ISO 12944 C4–C5 requirements for structural steel corrosion protection.
Petrochemical & Power Plants
Equipment and structures in petrochemical plant, power stations and chemical processing environments face chemical splashes, elevated temperatures and aggressive atmospheric corrosion. PLS52-1 TDI enamel and PLS52-4 high-solids anticorrosive topcoat provide robust chemical resistance and simplified coating schedules to reduce downtime.
Offshore Wind & Port Facilities
Wind turbine tower coating, offshore platform topsides and port steel infrastructure require non-yellowing, UV-stable finishes that maintain gloss and colour in marine C5-M atmospheres. PLS52-3 HDI aliphatic polyurethane topcoat delivers outstanding UV resistance and colour retention for offshore wind turbine tower coating and marine structural protection.
Vehicles & Engineering Machinery
Construction machinery, agricultural equipment and industrial vehicles require coating systems that resist mechanical abrasion, oil contamination and repeated washing cycles. The PLS52-1 and PLS52-3 polyurethane topcoat systems combine toughness, boiling-water resistance and decorative gloss to protect working machinery in harsh environments.
Related Articles & Guides
This guide covers the key decision points when specifying a 2-pack polyurethane system for corrosion categories C4 and C5: how to match TDI enamel vs HDI aliphatic topcoat to your UV exposure level, how to calculate total DFT across primer, intermediate and topcoat layers, and when to specify two coats of MIO intermediate in chemical plant environments. Includes a ready-to-use specification template compatible with ISO 12944-5 and NACE SP0108.
Request a Technical Recommendation
Tell us your substrate, environment and project scale — our technical team will recommend the right system and provide a quotation within 24 hours.
- Response within 24 hours
- Free technical consultation
- TDS & safety data sheets provided
