PLT-1 Modified Epoxy Phenolic Non-Carbon Conductive Anti-Static Coating

Overview
Two-component modified epoxy phenolic non-carbon conductive anti-static coating for internal linings of flammable liquid storage/transfer facilities.​

Composition
Special epoxy phenolic resin, conductive pigments, conductivity enhancer, solvent, amine curing agent; supplied as Part A & Part B.​

Typical uses
For coating of facilities requiring static dissipation for flammable liquid storage and transfer.​
For internal linings of petroleum product storage tanks and pipelines as a long-term conductive anti-corrosion coating, especially for methanol and ethanol tank internal walls.​

Technical data (typical)

• Appearance: grey, light grey.​

• Theoretical consumption: 0.19 kg/m² at 80 µm DFT (loss not included).​

• Density: 1.33 kg/L.​

• Drying time (25°C): surface dry 2 h; hard dry 24 h; full cure 7 d.​

Application data (25°C)

• Mixing ratio (A:B): 20:3.​

• Induction time: 5 min.​

• Pot life: 45 min.​

• Application methods: airless spray, brush, roller.​

• Thinner: dedicated thinner, 3–7%.​

• Recoat interval: min 24 h; max 7 d.​

• Recommended DFT per coat: 50–80 µm (brush/roller 30–50 µm).​

Surface preparation
Steel: blast to Sa 2.5 or power-tool clean to St 3; surface profile 30–75 µm.​

System compatibility / packing / storage

• Packing: Part A 20 kg; Part B 3 kg.​

• Storage: dry, cool, ventilated; away from fire; avoid strong sunlight; no outdoor storage.​

• Shelf life: 12 months.
